| Product Description | AOC 22B2H/EU - LED monitor - Full HD (1080p) - 22" |
| Device Type | LED-backlit LCD monitor - 22" |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/413333 |
| Energy Class | Class E |
| Energy Consumption per Year | 30 kWh |
| Power Consumption (On mode) | 18 W |
| Panel Type | VA |
| Aspect Ratio | 16:9 |
| Native Resolution | Full HD (1080p) 1920 x 1080 at 75 Hz |
| Pixel Pitch | 0.2482 mm |
| Brightness | 200 cd/m² |
| Contrast Ratio | 3000:1 / 20000000:1 (dynamic) |
| Response Time | 4 ms |
| Colour Support | 16.7 million colours |
| Colour Gamut | 77% Adobe RGB, 98% sRGB |
| Input Connectors | HDMI, VGA |
| Display Position Adjustments | Tilt |
| Screen Coating | 3H Hard Coating |
| Voltage | AC 120/240 V (50/60 Hz) |
| Colour | Black |
| Dimensions (WxDxH) - with stand | 49.278 cm x 16.294 cm x 38.811 cm |
| Weight | 2.1 kg |
| Environmental Standards | ENERGY STAR Qualified |
| Compliant Standards | FCC, EAC |
| Manufacturer Warranty | 3-year warranty |
Frameless
Besides looking modern and attractive, frameless designs enable seamless multi-monitor setups. Your cursor/windows will not be lost anymore in the dark abyss of bezels, when many displays are placed side by side.
Wide viewing angle
Wide viewing angle features display color accurately at viewing angles of up to 178°. This way, it does not matter where you choose to view it from, colors will be displayed perfectly.
HDMI
HDMI (High-Definition Multimedia Interface) is supported by the current gaming consoles, current GPUs, set-top boxes, supporting the HDCP digital content protection system.
Full HD resolution
Want to watch a Blu-ray movie in full quality, enjoy games in high resolution or read crisp text in office applications? Thanks to its Full HD resolution of 1920 x 1080 pixels, this monitor lets you do just that.
Low Blue Light
AOC Low Blue Light protects you from harmful blue light which, during long sessions, has been shown to cause eye strain, headaches, and sleeping disorders. The Low Blue Light feature reduces the harmful wavelengths emitted without sacrificing color composition, setting the experience free from the worry of eye damage.
| Colour |
Black
|
| Weight |
2.1 kg
|
| Response Time |
4 ms
|
| Diagonal Size |
22"
|
| Horizontal Viewing Angle |
178
|
| Vertical Viewing Angle |
178
|
| Aspect Ratio |
16:9
|
| OSD Languages |
Multilingual
|
| Energy Class |
Class E
|
| Energy Class (HDR) |
Class F
|
| Viewable Size |
21.5"
|
| Colour Support |
16.7 million colours
|
| Pixel Pitch |
0.2482 mm
|
| Contrast Ratio |
3000:1 / 20000000:1 (dynamic)
|
| Panel Type |
VA
|
| Screen Coating |
3H Hard Coating
|
| Backlight Technology |
WLED
|
| Display Type |
LED-backlit LCD monitor / TFT active matrix
|
| Horizontal Refresh Rate |
30 - 83 kHz
|
| Vertical Refresh Rate |
50 - 76 Hz
|
| Energy Consumption per Year |
30 kWh
|
| Brightness |
200 cd/m²
|
| Native Resolution |
Full HD (1080p) 1920 x 1080 at 75 Hz
|
| Dimensions (WxDxH) |
49.278 cm x 16.294 cm x 38.811 cm - with stand
|
| Features |
Low Blue Light Mode, Flicker Free technology, Wide Viewing Angle, 3-sided frameless
|
| Colour Gamut |
77% Adobe RGB, 98% sRGB
|
| Energy Label QR Code URL |
Https://eprel.ec.europa.eu/qr/413333
|
| Service & Support |
Limited warranty - 3 years
|
| Features |
Security lock slot (cable lock sold separately)
|
| Cables Included |
HDMI cable - 1.8 m
|
| Security Slot Type |
Kensington security slot
|
| Compliant Standards |
FCC, EAC
|
| Power Consumption (Typical) |
20 Watt
|
| Power Consumption Stand by |
0.3 Watt
|
| Power Consumption (Off Mode) |
0.3 Watt
|
| Power Consumption (On mode) |
18 W
|
| Input Voltage |
AC 120/240 V (50/60 Hz)
|
| Power Consumption SDR (On mode) |
16 kWh/1000h
|
| Power Consumption HDR (On mode) |
18 kWh/1000h
|
| Interfaces |
VGA
HDMI
Headphones
|
| Dimensions & Weight Details |
With stand - width: 49.278 cm - depth: 16.294 cm - height: 38.811 cm - weight: 2.1 kg
Without stand - width: 49.278 cm - depth: 3.62 cm - height: 29.268 cm
|
| Shipping Height |
37 cm
|
| Shipping Weight |
3.5 kg
|
| Shipping Depth |
12 cm
|
| Shipping Width |
55 cm
|
| Display Position Adjustments |
Tilt
|
| VESA Mounting Interface |
100 x 100 mm
|
| Tilt Angle |
